Muaj Dej Txias Chiller Chav nrog Hermetic Scroll Piston Hom Compressor
Muaj Dej Txias Chiller Chav Nrog Hermetic Scroll / Piston Hom Compressor
Cov ntsiab lus ceev:
KASSEL dej-txias lub thawv chiller tuaj yeem muab cov dej txias txias nrog qhov kub ntawm -10-+30 degree rau cov dej khov, cov cua txias faib thiab tag nrho lwm lub sijhawm xav tau cov dej txias tshaj -10 degree, Nws tuaj yeem tswj tau qhov kub thiab txias ntawm the mechanized zus tau tej cov kev lag luam niaj hnub, yog li zoo heev txhim kho cov efficiency thiab cov khoom zoo.
Nqe lus piav qhia:
.KASSEL dej-txias chiller yog ib yam khoom siv cua txias muab cov dej txias thiab siv tau rau lub sijhawm zoo li lub hauv paus cua txias tshuab thiab cov txheej txheem kev lag luam uas xav tau cov dej txias txias xws li chiller tau siv dav hauv nruab nrab cua txias system hauv kev tsim khoom thiab txheej txheem. ntawm metallurgy, petrochemical engineering, machinery, kws, khoom siv hluav taws xob, electroplating, electrophoresis, thiab lwm yam kev lag luam uas xav tau dej txias.
Daim ntawv thov:
Aluminium oxidation, ultrasonic tu thiab txias, luam ntawv, tawv tawv, nqus txheej, wallpaper
|
Model KWS |
20s |
25s |
30s |
40s |
50s |
60s |
|
|
Lub peev xwm txias |
10³ Kcal / H |
55.5 |
62.3 |
83.4 |
111.1 |
124.5 |
166.8 |
|
Kw |
64.6 |
72.4 |
97 |
129.2 |
144.8 |
194 |
|
|
Compressor |
Lub zog (Kw) |
14.7 |
17.9 |
23 |
29.5 |
35.8 |
45 |
|
Ntau |
2 |
2 |
2 |
4 |
4 |
4 |
|
|
Tag Nrho Lub Zog |
Kw |
18 |
20.5 |
28 |
35.5 |
42.5 |
55.3 |
|
Evaporator |
Daim ntawv |
Dej Tank Phaj Tube, Ua Haujlwm Zoo Plhaub-Thiab-Tube, Stainless Hlau Phaj |
|||||
|
Dej ntws (M³ / H) |
11.2 |
13 |
18 |
22 |
25 |
36 |
|
|
Interface Loj |
DN 50 |
DN 65 |
DN 65 |
DN 65 |
DN 65 |
DN 65 |
|
|
Condenser |
Daim ntawv |
Plhaub Thiab Tube Hom, Stainless Hlau Phaj |
|||||
|
Dej ntws (M³ / H) |
14 |
16 |
21 |
27 |
33 |
42 |
|
|
Interface Loj |
DN 50 |
DN 50 |
DN 50 |
DN 65 |
DN 65 |
DN 65 |
|
|
Chilled Dej Pump |
Lub zog (Kw) |
2.2 |
2.2 |
3 |
4 |
4 |
5.5 |
|
Lub taub hau |
33 |
28 |
28 |
31 |
31 |
32 |
|
|
Lub tank (L) |
250 |
300 |
350 |
500 |
600 |
600 |
|
|
Dimension |
L (Mm) |
1700 |
1800 |
1800 |
1800 |
2000 |
2400 |
|
W (Mm) |
1000 |
1000 |
1000 |
1200 |
1300 |
1300 |
|
|
H (Mm) |
1700 |
1700 |
1800 |
1800 |
1900 |
2000 |
|
|
Qhov hnyav (Kg) |
650 |
800 |
950 |
1500 |
1800 |
2000 |
|
|
Kev Tiv Thaiv Kev Nyab Xeeb |
Tsis tiav / Rov Qab Theem Ceeb Toom, Kev Tiv Thaiv Siab & Tsawg Voltage, Kev Tiv Thaiv Tshaj Tawm, |
||||||
|
Dej tsis txaus ceeb toom, tiv thaiv kev tiv thaiv khov, ncua kev tiv thaiv |
|||||||
|
Cov Cuab Yeej Cuab Yeej |
|
||||||
|
Lub tub yees |
R22 R407C R410A R404A R134A |
||||||
|
Hwj chim |
380V / 3PH / 50HZ |
||||||
Competitive Advantage:
1. Siv hermetic scroll compressor ntawm lub ntiaj teb sab saum toj hom thiab cov tub yees li qub ntawm cov npe nrov thoob ntiaj teb;
2. Txheem zoo stainless hlau multistage centrifugal twj thiab stainless hlau dej thawv
3. Siv High-efficiency cooper plhaub-thiab-tube condenser nrog cov xov sab nraud, kom ntseeg tau tias muaj cua sov hloov ntawm lub chiller
4. Siv cov khoom ntawm thoob ntiaj teb paub zoo Schneider Electric thiab imported microprocessor kub tswj
Yog hais tias muaj dej txias chiller chav tsev nrog hermetic scroll piston hom compressor caters rau koj yuav tsum tau, txais tos mus yuav cov khoom siv hauv Suav teb los ntawm peb lub hoobkas. Peb yog ib qho ntawm cov kws tshaj lij thiab cov muag khoom nyob hauv Suav teb uas tuaj yeem muab cov kev pabcuam thiab cov nqi sib txawv rau koj. Thiab cov kev pabcuam customized kuj muaj. Tsis txhob yig ntxiv lawm.
Cim npe nrov: muaj dej txias chiller chav tsev nrog hermetic scroll piston hom compressor, Tuam Tshoj, Hoobkas, lwm tus neeg, manufacturers, customized, nqe, ua nyob rau hauv Suav teb
