Kev txuag hluav taws xob Lub tshuab nqus tsev khov tshuab
Loj: los ntawm 0.5 mus rau 200m²
Highlight: tuaj yeem kho
Warranty: ib xyoos
Kev txuag hluav taws xob Lub tshuab nqus tsev khov tshuab
Cov yam ntxwv ntawm lub zog txuag lub tshuab nqus tsev vacuum freeze dryer
Nws suav nrog lub tshuab nqus tsev, tub yees, cua sov, thiab tswj cov tshuab. Kev ziab yog ua tiav los ntawm ib qho kev pub mis. Lub tshuab tub yees yog qhov zoo tshaj plaws configured, hom compressors yog siv, thiab cov khoom txhawb nqa txawv teb chaws yog siv rau ntau yam kev tiv thaiv (roj tsis txaus, overpressure, overheating, overload thiab tiv thaiv theem poob).
Qhov ntsuas kub qis tshaj ntawm lub txee tuaj yeem ncav cuag - 50 degree, uas tuaj yeem ua kom tiav khov ntawm ntau yam khoom.
Qhov ntsuas kub tsis tshua muaj dej ua los ntawm tooj liab liab tuaj yeem tiv taus - 85 degree qis.
Qhov ntsuas kub tsis tshua muaj dej nrog cov cuab yeej txias txias txog li - 60 degree (Zui qis kub - 70 degree ) txais cov cuab yeej cuab tam ntawm lub tuam txhab, nrog lub peev xwm loj, muaj peev xwm ntes tau, thiab txuag hluav taws xob. .
Lub tshuab nqus tsev yog nruab nrog lub zog siv qis thiab siv lub tshuab nqus tsev twj tso kua mis kom txuag hluav taws xob thiab txo lub sijhawm ziab.
Circulating nruab nrab hom, uniform kub dissipation, me me kub sib txawv, siab thiab tsawg-temperature ua hauj lwm, nrog * zoo, tsis muaj suab nrov, muaj kev ruaj ntseg thiab txhim khu kev qha, thiab muaj peev xwm ua hauj lwm rau ib tug ntev lub sij hawm nyob rau hauv ntau qhov chaw.

Stainless hlau nruab nrab circulating twj tso kua mis thiab tag nrho stainless hlau nruab nrab circulating pipeline systems muaj ntev corrosion kuj thiab kev pab cuam lub neej.
Stainless hlau hollow txee thiab stainless hlau ziab lub thawv yog tiaj, du, yooj yim los ntxuav, ruaj, ntev kev pab cuam lub neej, thiab tsis yooj yim rau paug.
Kev ua haujlwm ntawm txhua feem ntawm lub tshuab tag nrho yog qhov tseeb ntawm ib nrais muag, yooj yim rau tus tswv, kev ua haujlwm yooj yim, kev saib xyuas yooj yim, thiab kev tswj xyuas.
Lub chav ziab khaub ncaws yog nruab nrog lub qhov rais saib qhov pom thiab pom qhov pom kev, uas tuaj yeem saib xyuas cov txheej txheem ziab ntawm cov ntaub ntawv.
Zuag qhia tag nrho installation, compact qauv, zoo nkauj tsos, on-site installation, yooj yim rau tag nrho cov kev txav thiab kev thauj mus los.
Nrog programmable ntse kev tswj kev siv tshuab, cov txheej txheem ua haujlwm tuaj yeem paub txog kev tswj hwm kev tswj hwm tsis siv neeg. Yog tias tsim nyog, phau ntawv tswj, ntu ntsuas kub nce, PID tsis siv neeg hloov kho, thiab tswj tau siv tau.
Kev txuag hluav taws xob txuag cov khoom siv khov tshuab ziab khaub ncaws yog dav siv hauv kev lag luam khoom noj khoom haus, xws li txiv hmab txiv ntoo, tshuaj yej, nqaij nruab deg, Cordyceps, thiab lwm yam lag luam. Cov txiv hmab txiv ntoo, tshuaj yej, nqaij nruab deg, Cordyceps Sinensis, thiab lwm yam khoom ua tiav los ntawm lub zog txuag zaub mov lub tshuab nqus tsev khov kom qhuav tag khaws cov xim, aroma, saj, zoo, thiab cov khoom noj khoom haus ua ntej khov-qhuav. Ntxiv mus, hais txog kev txuag hluav taws xob, nws tuaj yeem txuag tau ntau dua 30% piv nrog cov cuab yeej zoo sib xws.
Parameter:
Qauv | KFD-1 | KFD-2 | KFD-5 | KFD-6 | KFD-8 | KFD-10 |
Peev xwm (Kg / Batch) | 10 | 20 | 50 | 60 | 80 | 100 |
Qhov chaw txee (㎡) | 1.1 | 2 | 5 | 6 | 8 | 10 |
Txee Loj (Mm) | 500*400 | 700*500 | 800*895 | 950*800 | 1000*800 | 1190*800 |
Txee Quantity (Layer) | 5+1 | 6+1 | 7+1 | 8+1 | 10+1 | 11+1 |
Qhov kub thiab txias (degree) | -60 rau +70 | |||||
Dej Catcher Temper (degree) | -65±5 | |||||
Max Catch Dej (Kg) | 15 | 30 | 75 | 90 | 120 | 150 |
Qhov kawg Vacuum | 1 | 1 | 1 | 2 | 2 | 2 |
Hluav taws xob (kW) | 12 | 16 | 22 | 34 | 34 | 41 |
Qhov Loj (Mm) | 2200*1000*2000 | 2500*1000*2300 | 2200*1200*2400 | 3500*1400*2430 | 3500*1400*2430 | 4540*1400*2450 |
Qhov hnyav (Kg) | 1500 | 2000 | 2500 | 3000 | 3500 | 3800 |
Kev muag khoom ua ntej:
* Thaum peb tau txais koj qhov kev nug, peb yuav teb koj tus email raws sijhawm thiab sim peb qhov zoo tshaj plaws los qhia koj lub tshuab ziab khaub ncaws uas haum tshaj plaws. Cov ncauj lus kom ntxaws tech kuj yuav muab rau koj.
* Peb tuaj yeem ua cov qauv kuaj rau cov neeg siv khoom.
Tom qab kev muag khoom:
* Yog tias ua tau, thov tuaj rau peb lub Hoobkas thiab peb yuav qhia cov neeg ua haujlwm tag nrho cov txheej txheem ntawm kev ziab kom qhuav. Lub sijhawm tsim nyog tshaj plaws uas yuav tsum tau ua kom khov-qhuav yuav raug kuaj los ntawm peb.
* Peb yuav tiv tauj koj, kom paub tseeb tias txhua feem ntawm lub tshuab ziab khaub ncaws ua haujlwm zoo. Ib xyoo warranty, pub dawb online pabcuam rau cov neeg siv khoom txawv teb chaws.


Rhiav:

Exhibition:



Cim npe nrov: Lub tshuab nqus tsev vacuum freeze dryer, Tuam Tshoj, Hoobkas, lwm tus neeg, manufacturers, customized, nqe, ua nyob rau hauv Suav teb
