Nyob rau hauv-situ Ordinary Freeze Dryer
Cov lus qhia ntxaws ntxaws ntawm in-site dog dig freeze dryer
Ua ntej, cov yam ntxwv tseem ceeb ntawm lub tshuab ziab khaub ncaws hauv tsev zoo tib yam:
(1) Lub tshuab no siv lub thoob ntiaj teb hom Fabkis Taikang compressor tub yees, uas muaj cua txias sai thiab tsis tshua muaj cua txias.
(2) Nws txais yuav 7-inch tseeb xim kov LCD npo tswj qhov system, uas yooj yim rau kev khiav lag luam thiab muaj zog.
(3) Industrial embedded operating system, ARM9 core tswj Circuit Court tsim, 32M nco 128M FLASH, ua haujlwm ceev teb, ntau cov ntaub ntawv khaws cia.
(4) Lub kaw lus tswj tau cia li txuag cov ntaub ntawv khov-qhuav thiab tuaj yeem saib nws hauv daim ntawv ntawm lub sijhawm tiag tiag thiab nkhaus keeb kwm. Tag nrho cov txheej txheem khov-qhuav yog qhov tseeb thiab meej.
(5) Lub tshuab ziab khaub ncaws yog ua los ntawm cov xim tsis muaj pob tshab plexiglass qhov rooj. Cov qauv yog meej thiab intuitive, thiab tag nrho cov txheej txheem ntawm lyophilization tuaj yeem pom.
(6) Lub tshuab nqus tsev twj yog txuas nrog lub ntsiab chav tsev siv lub thoob ntiaj teb tus qauv KF ceev connector, uas yog yooj yim thiab txhim khu kev qha.
(7) Lub tshuab no tuaj yeem khaws ntau lub voj voog kom qhuav, thiab siv U disk kom rho tawm cov ntaub ntawv mus rau lub computer, siv lub PC software los xauj thiab luam tawm hauv computer thiab ntau yam kev xaiv.
(8) Lub tshuab ua haujlwm muaj ob hom kev ua haujlwm: kev tuav haujlwm thiab kev ua haujlwm tsis siv neeg, uas zoo heev rau kev xaiv ntawm kev ua haujlwm khov-qhuav.
(9) Cov txheej txheem tswj hwm muaj 36 lub tshuab ziab khaub ncaws kom qhuav, txhua qhov muaj 40 ntu ntawm kev tswj qhov kub thiab txias, uas tuaj yeem sau cov txheej txheem khov-qhuav ntawm ntau yam ntaub ntawv, thiab xaiv ncaj qha rau lub sijhawm khov-kho kom qhuav. ib yam khoom. Program.
(10) Qhov kev nce nqi valve tau teeb tsa kom ntim nrog cov roj inert;
(11) Qhov kub ntawm qhov sib cais yog kho tau, tswj tau, groping, tsav thiab txheej txheem ntau lawm
(12) Nws yog nruab nrog phau ntawv thiab tsis siv neeg ua haujlwm hom, uas tuaj yeem siv los tshawb xyuas qhov khov-drying nkhaus ntawm cov ntaub ntawv tshiab.
Thib ob, lub tshuab ziab khaub ncaws hauv tsev zoo tib yam xaiv tau muaj nuj nqi:
* eutectic point test muaj nuj nqi.
* Lub tshuab nqus tsev tswj kev ua haujlwm kom ua kom muaj cua sov loj,
* Muab ob npaug rau-tshuab cascade tub yees system nrog cov cuab yeej paub tab thiab tsis kub rau -80 degree khov tshuab;
* Lub qhov ncauj dav manifold khov-qhuav lub raj mis configuration, yooj yim nqa cov ntaub ntawv, tuaj yeem txuas nrog cov txheej txheem khov-qhuav lub raj mis valve. Standard 6 tubes.
* Xaiv lub tshuab nqus tsev twj tso kua mis.
Chav qhuav | Qhov project: | Hom li qub | |
| Qhov chaw qhuav: | 0.31㎡ | ||
| Number ntawm txheej: | 3 txheej | ||
| Txheej txheej: | 70 hli | ||
| Laminate loj: | 240mm × 430 hli | ||
| Khoom siv phaj loj: | 240mm × 430 hli | ||
| Plated khoom: | feem 4l | ||
| Xilin lub raj mis | Ø12: | 2256 ib | |
| Ø16: | 1260 ib | ||
| Ø22: | 650 ib | ||
| Kev tswj qhov kub ntawm qhov muab faib: | -45 degree -50 degree | ||
| Hluav taws xob cua sov phaj: | 36V kev nyab xeeb voltage, silicone roj hmab hluav taws xob cua sov phaj | ||
| Lub tshuab ziab khaub ncaws: | SUS 304 | ||
| Drying Chamber Shape: | cylindrical | ||
| Daim ntawv cua sov: | hluav taws xob cua sov | ||
| Drying Chamber Loj: | 600 hli | ||
| Drying room installation txoj kev: | kab rov tav | ||
| Qhib qhov rooj: | sab pem hauv ntej yog qhib rau sab laug | ||
| Cov khoom siv ntawm qhov rooj: | ACRYLIC | ||
Dej ntxiab | Cov duab: | integrated nrog lub tshuab ziab khaub ncaws |
| loj: | ||
| Khoom siv: | SUS 304 | |
| Txias rooj qhov rooj: | sab laug qhib ACRYLIC (acrylic) | |
| Txoj kev ua kom txias: | puab coil | |
| Qhov ntsuas cua txias txias: | +20 degree C mus rau -40 degree C / 30 feeb | |
| Txoj kev ua kom txias: | puab coil | |
| Water catching peev: | 6-8 litres | |
| Qhov kub thiab txias: | <-56℃ | |
Lub tshuab nqus tsev | Lub tshuab nqus tsev twj: | 2XZ-4 lub tshuab nqus tsev vacuum imported |
| Vacuum sojntsuam: | Pirani kuj silicon | |
| Ultimate nqus tsev vacuum: | <10Pa | |
| Inflator valve: | stainless hlau phau ntawv inflation valve | |
| Nqus interface: | KF thoob ntiaj teb tus qauv interface | |
Txias System | Lub tub yees: | Taikang Compressor (1.5P) 1set |
| Condenser: | 8.2m2 ua | |
| Expansion valve: | Danfoss ST 2 | |
| Lub tank ua kua: | Tebchaws Asmeskas Slovakia | |
| Solenoid valve: | Danfoss | |
| Kev ntsuas kub: | PT100 platinum tsis kam | |
| Phaj Thaum tshav kub kub Exchanger: | Alfa Laval | |
| Cov tub yees: | Mixed refrigerant ntawm R23 | |
| Lub cev tooj liab: | 10 | |
| Txoj kev ua kom txias: | Cua txias: zoo ventilated Chav tsev kub tsawg dua los yog sib npaug rau 25 degree | |
Tswj System | LCD npo: | 7 nti muaj tseeb xim LCD npo |
| Tus tswj | Industrial embedded arm controller | |
| Cua sov transformer: | 800W nplhaib rho tawm transformer | |
| Kev ntsuas kub: | PT100 platinum tsis kam | |
| Solid State Relay: | American Express | |
| Switching Power Supply: | Taiwan Ming Wei | |
| Cua hloov: | Schneider | |
| Lub zog hluav taws xob: | 220v 50HZ ib | |
| Nruab lub zog: | 2 KW | |
| Tshuab qauv: | kev koom ua ke | |
| Qhov Loj: | 1050×700×1460< | |
| Tshuab zoo: | 280 KG |
